Blueprint Reading For Beginners – North
June 25 @ 8:30 am - 5:00 pm
$750.00
6/25 & 6/26/2024
About Course:
This two-day training course has been designed for people who want to understand how to read blueprints. The class will be live with an NJMEP Expert Resource with constant discussion between students and the instructor. Question and answer sessions will take place during the course to ensure knowledge and understanding this two-day training course has been designed for people who want to understand how to read blueprints. The class will be live with an NJMEP Expert Resource with constant discussion between students and the instructor. Question and answer sessions will take place during the course to ensure knowledge and understanding.
Topics to be covered:
I. Basics of Blueprints
II. Reading Blueprints
III. Lines and Views
IV. Dimensions
V. Tolerances
VI. Surfaces/Finishes
VII. Machine Terms and Holes
VIII. Intro to GD & T (Geometric Dimensioning and Tolerancing)
IX. Other Topics
a. Screw Threads
b. Bills of Material (BOM) references
c. Schematics
